Alwarerc Eagle Pro V3 Tilt & Pan Upgrade Pack with 360 Continuous Servo - Manual (Page 10)

4.2 Assembly Steps –
Installation of Upgrade Outer Frame
Step 1.
Prepare the Upgrade Outer Frames, 360 degree
continuous servo and other parts as shown above. Step 2.
Install the Alu Rods, fiber frames and Pan Bearing
Mounts onto the Upgrade Outer Frame using
M2x6mm Screws, and M2.5x8mm Screws for the Pan
Bearing Mounts.
(Apply little amount of Thread Locker
to the screws when installing metal parts.)
Step 3.
Make sure that Four Flange Bearings on the Outer
Frame is supporting the Inner Circle Assembly tightly
and correctly. Step 4.
Install 4pcs Flange Bearings and 8pcs Nylon washers
again.
Page 10 of 15
