Step 5.
Installation of the Gyro Mounting Frame onto the
Upgrae Outer Frames. Step 6.
Insert the other side of Upgrade Outer Frame and
secure it with M2X6mm Hex Cap Screws for Alu
Rods and M2.5x8mm Screws for the Pan Bearing
Mounts.
(Apply little amount of Thread Locker to the
screws when installing metal parts.)
Step 7.
Hole and compress two Alu Roll Bearing shafts with
hand and tighten the shafts using M2x6 Hex Cap
Screws .(This step will affect the smoothness and
tolerance of the Roll Axis movement.)
Page 11 of 15
