location. You can turn on and off, and even dim other Z-Wave devices once they are “ associated” into 1 of 4 groups
within the ZDW232.
Each group is turned on or off (brightened or dimmed) by tapping or holding the switch a differing amount of times.
Group 1 Control: If you associate a Z-Wave device into Group 1, you can turn that device ON and OFF by tapping
the top or bottom of the switch once. The load attached to the ZDW232 will also turn on or off. Associating nodes
into group 2 or 3 will cause a very slight delay before the command is transmitted to group 1 nodes.
You can brighten the controlled device by pushing and holding the top of the switch, dim by pushing and holding
the bottom of the switch.
Group 2 Control: If you associate a Z-Wave device into Group 2, you can turn that device ON and OFF by tapping
the top or bottom of the switch twice. You can brighten or dim devices by tapping the switch once then push and
hold the top or bottom. The load attached to the ZDW232 is not affected.
Group 3 Control: If you associate a Z-Wave device into Group 3, you can turn that device ON or OFF by tapping
the top or bottom of the switch three times. You can brighten or dim devices by tapping the switch twice then push
and hold the top or bottom. The load attached to the ZDW232 is not affected.
Group 4 Control: Only associate transmitters or controllers into Group 4. Group 4 should be used only to update
a transmitter or controller on the status of the ZDW232 which might have been controlled from another device.
You can associate up to 5 Z-Wave devices into each of these four groups. For instructions on how to “ associate”
a Z-Wave device into one of these groups, refer to your wireless controller instructions. (If you are using the
ZTH200 controller, refer to the Setup Menu, Association section).
A note about dimming, if you combine Z-Wave enabled dimmers and other types of Z-Wave devices in a group,
place a Z-Wave enabled dimmer into the empty group 1
st to ensure that the dimming operates correctly.
Configuration
The ZDW232 supports the Configuration command.
The ZDW232 can be configured to operate slightly differently than how it works when you first install it. Using the
Configuration command you can configure the following:
• Set Ignore Start Level Bit When Transmitting Dim Commands
• Suspend Group 4
• Disable Group 4 During a Dim Command
• Night Light
• Invert Switch
• Ignore Start Level When Receiving Dim Commands
• Ignore Start Level When Receiving Dim Commands
• Don’t Send Level Command After Transmitting Dim Commands
• Adjusting Dim Rate
• On/Off Command dim rate (excluding ALL ON/ALL OFF commands)
• Enable Shade Control Group 2
• Enable Shade Control Group 3
• LED Transmission Indication
You can use a ZTH200 to send Configuration commands. (Refer to the Setup Menu, Configuration section)
Set Ignore Start Level Bit When Transmitting Dim Commands
• Parameter No: 1
• Length: 1 Byte
• Valid Values = 0 or 1 (default value is 1)
The ZDW232 can send Dim commands to Z-Wave enabled dimmers. The Dim command has a start level embedded
in it. A dimmer receiving this command will start dimming from that start level. However, the command also has a
bit that indicates whether the dimmer should ignore the start level. If the bit is set to 1, the dimmer will ignore the
start level and instead start dimming from its current level. If this bit is set to 0, the dimmer will not ignore the start
level.
