ZDW232 Instructions, Release 1.1
P/D 100407 HomePro
by ADVANCED CONTROL TECHNOLOGIES, INC.
0747-01
2
INCLUDING ZDW232 TO THE NETWORK
Including to the Network (Must be installed in its permanent location, not on test bench).
1. Setup the controller you are using to include a device into network.
2. Tap either the top or bottom of the switch once
Excluding from the Network
1. Setup the controller you are using to exclude a device from the network.
2. Tap either the top or the bottom of the switch once.
BASIC OPERATION
Local Control
From the switch, the ZDW232 allows the user to do the following:
• Turn ON or OFF, BRIGHTEN or DIM, the load attached.
• Include or exclude the module from the Z-Wave network.
• Configure to Control Shades or Window Coverings via Z-Wave network.
• Control other Z-Wave enabled devices.
Also, when a controller prompts you to “Send Node ID” or to “Press Button on Unit”, quickly tap the top or bottom
of the switch once to satisfy those instructions.
• Tapping top of the switch turns the load attached ON.
• Tapping bottom of the switch turns the load attached OFF.
• Pressing and holding the top of the switch will brighten the load attached, and pressing and holding the
bottom of the switch will dim the load. When OFF, pressing and holding the bottom of the switch will
cause the load will go to the minimum dim level. Caution: When dimmed to the lowest setting,
even though the load looks like its off, it still has power. Tap bottom of switch to turn off com-
pletely. It is best to turn off the power at the circuit breaker to service the load.
Note: Upon restoration of power after a power loss, the ZDW232 does not return to previous known state.
LED indication
The LED on the ZDW232 will turn on when the load attached is ON. However, the LED can be user configured to
turn ON when the load attached is OFF, if so desired, to act as a night light.
The ZDW232 will flicker its LED when it is transmitting to any of its 4 groups. This can be changed if desired.
See “LED Transmission Indication”.
Remote Control
The ZDW232 will respond to BASIC and MULTILEVEL commands that are part of the Z-Wave system. Refer to your
controller’s instructions as to whether your controller can transmit those commands.
ADVANCED OPERATION
All On/All Off
The ZDW232 supports the ALL ON/ ALL OFF commands.
The ZDW232 can be set to respond to ALL ON and ALL OFF commands 4 different ways.
Refer to your controller for information on how to set the ZDW232 to operate in the manner you desire. Some
controllers may be only able to set certain settings of ALL ON/ALL OFF response.
The 4 different ways the ZDW232 can be setup to respond to ALL ON and ALL OFF commands are:
• ZDW232 will not respond to ALL ON or the ALL OFF command.
• ZDW232 will respond to ALL OFF command but will not respond to ALL ON command.
• ZDW232 will respond to ALL ON command but will not respond to ALL OFF command.
• ZDW232 will respond to ALL ON and the ALL OFF command (default).
Association
The ZDW232 supports the Association command.
The ZDW232 can be set to control other Z-Wave devices. Those devices must be installed in their permanent
