ADVANCED CONTROL TECHNOLOGIES, INC.

Indianapolis, Indiana 46278

AT004 Operating Instructions
P/D 110409

SECTION K. AUTO FUNCTIONS

There are several auto functions available on the AT004.
P1AUT0, LETTER CODE REPEAT, and LETTER CODE ON/OFF REPEAT...........

After pressing the LETTER CODE key, the LCD will display..................................

To Select P1AUTO, press the P1AUTO key. The LCD will display..........................

Press the TRANSMIT key to begin transmitting P1 PON POFF.

To Choose an auto-repeat "alpha one" address with ON/OFF command (i.e. A1, B1, C1...through P1):

Press the LETTER key, and then choose a letter.

Then Press the COMMAND key and choose AUTO REPEAT address on/off..........

Press the TRANSMIT key to begin transmitting the selected letter code with the
ON and OFF commands. NOTE: Only a "numerical 1" address is available for Auto-Repeat

To only transmit an "alpha one" address with no command:

Press the LETTER key, and then choose a letter.

Then Press the COMMAND key and choose AUTO REPEAT (address only).........

Press the TRANSMIT key to begin transmitting the selected letter code without the
ON and OFF commands.

The PAUSE key can be used to temporarily suspend transmission of any auto transmission. It can be pressed
again to restart it.

SECTION L . SETUP

When power is applied to the AT004 the LCD will display the following for 2 seconds.

After 2 seconds, the LCD displays......................................................................

During these 4 seconds, you can press the PAUSE key to enter SETUP mode.....

You can use the UP/DOWN buttons to scroll through the SETUP OPTIONS as follows:

1. Tx Voltage
2. Tx Location
3. Set Time/Date
4. Clear Logs
5. Exit

Code to Transmit

P1Auto

Code Transmitted

P1Auto

Code Transmitted

BrptOnOf

Code Transmitted

BrptAddr

ACT AT004 V1.0

A10 and X10

ACT AT004 V1.0

01-01-00 12:00

Setup Menu

1. TX Voltage
