0378-01
4
ADVANCED CONTROL TECHNOLOGIES, INC.
Indianapolis, Indiana 46278
AT004 Operating Instructions
P/D 110409
SECTION B. TRANSMIT CONT’D
The letter key can be pressed again, and the display will show.....................
(The desired letter can be selected as described above, but will likely
be the same as the letter in the first frame).................................................
The command can be entered after pressing the SET COMMAND
key described above
Press the TRANSMIT key to transmit the selected PCC code.
The LCD will display.................................................................................
The code can be retransmitted by pressing the TRANSMIT KEY again.
(The “Code Transmitted” line will flash briefly to indicated another transmission.
Note that when a request command (HAIL REQUEST, STATUS REQUEST) is transmitted, the AT004
will automatically enter FRAME DETAILS mode so that any response can be seen.
To retransmit the request command, the SET LETTER key must be pressed. The request string
will automatically be setup on the LCD. To transmit the command again, press the TRANSMIT key.
Transmitting extended code is explained in SECTION J.
The use of AUTO commands available on the AT004 are explained in SECTION K.
To change Tx signal level or location, see Section L: Setup, Options 1 and/or 2
SECTION C. FUNCTION KEYS
To log noise, press the LOG NOISE key and go to Section D........................
To log signal, press the LOG FRAMES key and go to Section E....................
(NOTE: This function only gives frame details, not signal voltage).
To see noise data (average noise and noise at the zero crossing), press the
NOISE DATA key and go to Section F........................................................
To see signal data (signal strength, and X -10 code) press the SIGNAL DATA
key and go to Section G............................................................................
To see signal and noise data (X10 signal strength and noise strength),
press the SIGNAL and NOISE DATA key and go to Section H.....................
To see received X10 frames in detail, press the FRAME DETAILS key
and go to section I.....................................................................................
SIGNAL and
NOISE
DATA
0xE
NOISE
DATA
0xC
LOG
FRAMES
0xB
SIGNAL
DATA
0xD
FRAME
DETAILS
0xF
LOG
NOISE
0xA
TRANSMIT
(ENTER)
Code to Transmit
A01 A
Code to Transmit
A01 A-on-
Code Transmitted
A01 A-on-
