0378-01
3
AT004 Operating Instructions
P/D 110409
ADVANCED CONTROL TECHNOLOGIES, INC.
Indianapolis, Indiana 46278
SECTION A. POWER UP
When power is applied to the AT004 the LCD will display the following for 2 seconds..
After 2 seconds, the LCD will display.....................................................................
After another 2 seconds the AT004 enters the SIGNAL AND NOISE DATA
MODE and the LCD will display.............................................................................
Title Screens can also be reached by holding the "Press and Hold for Restart" Button
for 5 seconds. Power does not have to be removed.
SECTION B. TRANSMIT
All valid PCC codes will contain a letter code. To begin the process of
choosing a code to transmit, the SET LETTER key must be pressed.
After pressing the SET LETTER key, the LCD will display.......................................
The letter can now be chosen by pressing the desired letter key
(shown in blue on the white keys on the keypad). The display will toggle
between the two letter codes when the key is pressed.
After selecting the desired letter, either the SET COMMAND, SET
NUMBER OR TYPE, or SET EXTENDED CODE key must be pressed.
If the SET COMMAND key is pressed, then the desired command
can be selected by pressing the appropriate key (commands are in
black on the white keys). The display will toggle between the two command
codes when the key is pressed.............................................................................
If the SET NUMBER OR TYPE key is pressed, then the desired number
can be selected by pressing the appropriate keys (numbers are in
red on the white keys)..........................................................................................
If the SET EXTENDED CODE is pressed, then you must enter
extended code information. More information on how to use the AT004
for extended code is given in SECTION J.
NORMALLY, you will want to enter a LETTER / NUMBER CODE,
then a LETTER / COMMAND combination. In this case, after the
letter code and number code has been entered as shown here (see next page)…......
Code to Transmit
A01
To Transmit go to Section B. Otherwise go to Section C.
SET
NUMBER
OR TYPE
SET
COMMAND
SET
LETTER
SET
EXTENDED
CODE
Code to transmit
A-on-
Code to transmit
A01
Code to Transmit
A
ACT AT004 V1.0
A10 and X10
ACT AT004 V1.0
01-01-00 12:00
Noise X-10
700mv 0.00V
