Description of interfaces and

functions

Document: Manual_Medical_MLC_1.2

Page 12 of 37 pages

Last change date: 18-Feb-15

6. D

ESCRIPTION OF INTERFACES AND FUNCTIONS

This chapter provides some further information and explanations regarding the device interfaces. For

proper interface operation and handling instructions please refer also to chapter 10 Cleaning.

Note: All interface pin outs comply with the technical standards (please refer to appropriate internet

sites), deviations thereof or non-standard interfaces are documented separately.

Warning for medical appliances:

Accessory equipment connected to the analogue and digital interfaces must be

certified according to the respective IEC standards (e.g. IEC 950 for data pro-

cessing equipment and IEC 601-1 for medical equipment). Furthermore all

configurations shall comply with the valid version of the system standard IEC

601-1-1. Everybody who connects additional equipment to the signal input part

or signal output part configures a medical system, and is therefore responsible

that the system complies with the requirements of the valid version of the sys-

tem standard IEC 601-1-1. If in doubt, consult the technical service department

or your local PENTA representative.

6.1. Interfaces and controls

6.1.1. Location

Figure 2: Location of interfaces, bottom view without cable cover

Figure 3: Inscription of interfaces on connector/slot panel
