MLC 4-xx Technical Manual Rev. 1.2 System overview
Document: Manual_Medical_MLC_1.2 Page 11 of 37 pages Last change date: 18-Feb-15
RAM up to max 16GByte DDR3 1066/1333/1600 SO-DIMM in 2 sockets
Graphics Intel HD 4600 with triple display support, base frequency 400MHz
Storage mSATA SSD and/or 2.5” SSD/HDD connected to SATA III (6.0Gbit/s)
For available capacities please contact your PENTA representative
Note: 2.5” SSD/HDD is exchangeable by user.
Sound codec Intel HDA compliant
OS compatibility Intel x64 micro architecture compliant
5.3. Interfaces
For a more detailed description of the interfaces please refer to chapter 6. Description of interfaces.
LC Display MLC 4- 21: 21.5”/54,6cm full HD (1920x1080, 16:9), 16.7Mio colors, brightness 250 [cd/m²] with
adjustable LED backlight
Touch Optional: 21.5”/54,6cm 5 point multitouch PCAP
Graphics interface 2x HDMI V1.4a compliant
1x VGA
USB ports 2x USB 2.0 (HighSpeed with up to 480Mbit/s)
2x USB 3.0 (SuperSpeed with up to 5Gbit/s)
Network 2x Ethernet 10/100/1000Mbit/s (10/100/1000BASE-T)
Sound MIC IN, LINE out
COM ports 3x RS-232
Optional: 2x RS-232 galvanically isolated
Keys and signal LEDs Power button (left side), four keys and two LEDs (right side)
Power In Wide AC input range (110 …240V~,50…60Hz)
5.4. Options
The following table show options and add on parts for the MLC:
Part number Type Description
