MilSystem Setup
MilSystem User’s Guide 15
*Requires external display power supply and display power inverter.
37 LVDS 12 LVDS_IYBM1 Channel 2, line 1, data
negative
38 LVDS 13 LVDS_IYBP0 Channel 2, line 0, data
positive
39 LVDS 14 LVDS_IYBM0 Channel 2, line 0, data
negative
40 LVDS 15 LVDS_PANELBKLTCTL* Controls Panel Backlight
41 LVDS 16 LVDS_PANELVDDEN Enables Panel Power
42 LVDS 17 CLK_LVDS_IYAP Channel 1 clock positive
43 LVDS 18 CLK_LVDS_IYBM Channel 1 clock negative
44 LVDS 19 LVDS_IYAP3 Channel 1, line 3, data
positive
45 LVDS 20 LVDS_IYAM3 Channel 1, line 3, data
negative
46 LVDS 21 LVDS_IYAP2 Channel 1, line 2, data
positive
47 LVDS 22 LVDS_IYAM2 Channel 1, line 2, data
negative
48 LVDS 23 LVDS_IYAP1 Channel 1, line 1, data
positive
49 LVDS 24 LVDS_IYAM1 Channel 1, line 1, data
negative
50 LVDS 25 LVDS_IYAP0 Channel 1, line 0, data
positive
51 LVDS 26 LVDS_IYAM0 Channel 1, line 0, data
negative
52 LVDS 27 LVDS_DDCPCLK Display Data Channel
Clock
53 LVDS 28 LVDS_DDCPDATA Display Data Channel Data
54 LVDS 29 LVDS_PANELBKLTEN* Enable Panel Backlight
Inverter
55 LVDS 30 Chassis Shield
Table 9. MC-3 Connector Pin Signals (Continued)
Pin # Breakout Cable
Connector Breakout
Cable Pin # Signal Signal Description
