14
1.12.2 P3 Pin Definitions
Table 1-5 Provides the pin definitions and signal maps for the P3 Military Connector.
P3
Pin
Interface Signal Signal Description
HIBR
Pin
Interface
Board
Pin
1 VGA VGA_VSYNC Vertical Sync 40 CN1-11
2 Ground GND Ground 207 NA
33 Ground GND Ground 8 NA
3 VGA VGA_DDC_SCL Display Data Channel -
Serial Clock 10 CN1-7
4 VGA VGA_DDC_SDA Display Data Channel -
Serial Data 20 CN1-8
5 Ground GND Ground 237 NA
6 VGA RED Red Analog Output 29 CN1-5
18 Ground GND Ground 297 NA
7 VGA GREEN Green Analog Output 19 CN1-3
21 Ground GND Ground 347 NA
14 VGA BLUE Blue Analog Output 9 CN1-1
30 Ground GND Ground 367 NA
8 VGA HSYNC Horizontal Sync 30 CN1-10
9 Power P3V3_S +3.3 Volts Standby NA NA
10 Power P3V3_S +3.3 Volts Standby NA NA
11 Ground GND Ground 267 NA
12 Power P3V3_S +3.3 Volts Standby NA NA
13 Power P3V3_S +3.3 Volts Standby NA NA
15 Power P3V3_S +3.3 Volts Standby NA NA
38 Ground GND Ground 38 NA
24 Control/Indicator PCIe_ETH_5/5_LED1 Ethernet LED 164 CN1-58
99 Ground GND Ground 99 NA
114 Control/Indicator PCIe_ETH_4/5_LED1 Ethernet LED 174 CN1-55
99 Ground GND Ground 99 NA
121 Control/Indicator PCIe_ETH_3/5_LED1 Ethernet LED 32 CN1-49
99 Ground GND Ground 99 NA
16 Gigabit Ethernet 4 GbE5_MDI0_N Ethernet4 MDI0
Negative 185 CN2-56
17 Gigabit Ethernet 4 GbE5_MDI0_P Ethernet4 MDI0 Positive 195 CN2-55
18 Ground GND Ground 347 NA
19 Gigabit Ethernet 4 GbE5_MDI1_N Ethernet4 MDI1
Negative 75 CN2-41
20 Gigabit Ethernet 4 GbE5_MDI1_P Ethernet4 MDI1 Positive 65 CN2-40
21 Ground GND Ground 347 NA
22 Gigabit Ethernet 4 GbE5_MDI2_N Ethernet4 MDI2
Negative 74 CN2-44
23 Gigabit Ethernet 4 GbE5_MDI2_P Ethernet4 MDI2 Positive 64 CN2-43
Table 1-5: P3 Connector Pin Signals
