Getting Started 31
NuPRO-E72
COM1 Mode Switch (SW13)
2.6 Driver Installation
This chapter provides information on how to install the NuPRO-
E72 device drivers under Windows 7 64-bit. The device drivers are
located in the following ADLINK All-in-One DVD directories:
Install the Windows operating system before installing any driver.
Most standard I/O device drivers are installed during Windows
installation.
DIP #1 DIP #2 COM1 Mode
On Off RS-232
On On RS-422
Off On RS-485
Chipset \NuPRO\NuPRO-E72\Chipset\
Display \NuPRO\NuPRO-E72\VGA\
Ethernet \NuPRO\NuPRO-E72\Ethernet\
Rapid Storage \NuPRO\NuPRO-E72\Others\RST\
USB 3.0 \NuPRO\NuPRO-E72\Others\
Management
Engine \NuPRO\NuPRO-E72\Others\ME_Driver\
NOTE: NOTE:
In order to enable RAID or AHCI mode, you must pre-install the
Intel® Rapid Storage Technology driver during the Windows*
installation process. using the F6 installation method.
*Not required for Windows Vista and Windows 7.
ON
1 2 3
ON
1 2
