Introduction 3
NuPRO-E72
I/O Interfaces
I/O Ports
• 6x USB 3.0 ports (2x on rear panel, 4x on SHB)
• 4x USB 2.0 on backplane
• 4x SATA 6 Gb/s on SHB
• 6x serial ports via onboard pin-header
(5x RS-232, 1x RS-232/422/485 with auto flow control)
• 2x Gigabit Ethernet RJ45 ports
• 1x VGA port (Dsub-15)
• 1x DVI-D via onboard pin-header (opt. cable bracket
)
• Pin header for HD Audio DB-Audio2 daughter board
• 1x PS/2 KB/MS via onboard pin header (opt. cable
bracket)
PCIe/PCI
• PCIe-x16 (or two PCIe x8 or one PCIe x8 and two PCIe
x4)Gen3
• PCIe-x4 (or four PCIe x1) and PCI 32bit/33MHz (TI
XIO2001) via golden fingers
Graphics
Integrated Integrated Intel® HD Graphics
External PCI Express x16
Ethernet
Controller
• Dual Gigabit Ethernet (Intel® I217LM Gigabit Ethernet
PHY, Intel® I211-AT Gigabit Ethernet Controller)
• Supports Preboot Execution Environment (PXE), Wake-
On-LAN, and Intel® AMT 9.0 on LAN1 (I217LM)
Ports Two RJ-45 Ethernet ports
Mechanical and Environment
Form Factor Standard full-size PICMG 1.3 SHB
Dimensions 338 x 126 mm (L x W)
Operating
Temp.
0ºC to 60ºC
Storage Temp. -20ºC to 80ºC
Rel. Humidity 10% to 90% non-condensing
Safety CE, FCC Class A
