Introduction 3
MXE-5300
1.3 Specifications
MXE-5301 MXE-5302 MXE-5303
System Core
Processor
Intel
®
Core™ i7-
2710QE
Intel
®
Core™
i5-2510E
Intel
®
Core™
i3-2330E
Chipset
Intel
®
Mobile Platform Controller Hub (QM67)
Video VGA+DVI dual display output by DVI-I connector
Analog CRT, supports QXGA (2048 x 1536) res.
DVI output, supports up to 1920 x 1080 res.
Memory 4 GB DDR3 1066 MHz SODIMM module (Up to 8
GB support)
I/O Interface
Ethernet
4 GbE ports (2 Realtek
®
8111C + 1 Intel
®
82574IT
+ 1 82579 PHY)
Serial Ports 2 software-programmable RS-232/422/485
(COM1 & COM2)
2 RS-232 (COM3 & COM4)
USB 4 USB 2.0 ports & 2 USB 3.0 ports
DIO 4 DIO w/ 1.5KV isolation
Audio 1 mic-in and 1 speaker-out
KB/MS 1 PS/2 keyboard and 1 PS/2 mouse (combo)
Mini PCIe 2 internal PCIe mini card sockets
USIM 1 USIM socket for 3G communication (used for a
3G-mini module )
WDT Supports watchdog timer
Power Supply
DC Input
Built-in 9-32 VDC wide-range DC input
3P pluggable connectors with latch (GND, V-, V+)
