ETX-Proto User’s Manual

2.6 I2C and SMBus Devices

The SMBus (I2C bus) controller is integrated in the ETX core module. There are several
slave devices that reside on the SMBus (I2C bus) of the ETX-Proto. The addresses are as
follows:

Address

Device Function

Chipset

00101010

H/W monitor

Winbond W83782D

10011100

GPIO & Watch Dog Timer

Fintek F75111R
