Page 19 ETX-Proto User’s Manual
Pin Signal Pin Signal
1 NC 2 NC
3 NC 4 NC
5 NC 6 NC
7 NC 8 NC
9 NC 10 NC
11 NC 12 NC
13 NC 14 NC
15 GND 16 NC
17 INTA# 18 +5V
19 +3.3V 20 INTD#
21 NC 22 NC
23 GND 24 +3.3V_SB
25 PCICLK 26 RST#
27 GND 28 +3.3V
29 REQ# 30 GNT#
31 +3.3V 32 GND
33 AD31 34 PME#
35 AD29 36 NC
37 GND 38 AD30
39 AD27 40 +3.3V
41 AD25 42 AD28
43 NC 44 AD26
45 CBE3# 46 AD24
47 AD23 48 IDSEL
49 GND 50 GND
51 AD21 52 AD22
53 AD19 54 AD20
55 GND 56 PAR
57 AD17 58 AD18
59 CBE2# 60 AD16
61 IRDY# 62 GND
Pin Signal Pin Signal
63 +3.3V 64 FRAME#
65 NC 66 TRDY#
67 SERR# 68 STOP#
69 GND 70 +3.3V
71 PERR# 72 DEVSEL#
73 CBE1# 74 GND
75 AD14 76 AD15
77 GND 78 AD13
79 AD12 80 AD11
81 AD10 82 GND
83 GND 84 AD9
85 AD8 86 CBE0#
87 AD7 88 +3.3V
89 +3.3V 90 AD6
91 AD5 92 AD4
93 NC 94 AD2
95 AD3 96 AD0
97 +5V 98 NC
99 AD1 100 NC
101 GND 102 GND
103 NC 104 GND
105 NC 106 NC
107 NC 108 NC
109 NC 110 NC
111 NC 112 NC
113 NC 114 GND
115 NC 116 NC
117 NC 118 NC
119 NC 120 NC
121 NC 122 MPCIACT#
123 +5V_A 124 +3.3V_SB
CN2: 32-bit Mini PCI Connector
