6.6 X4 Connector: IDE1, IDE2, Ethernet, Miscellaneous
Signals and Pinout
Pin
Signal
Pin
Signal
1
GND
2
GND
3
5V_SB
4
PWGIN
5
PS_ON
6
SPEAKER
7
PWRBTN#
8
BATT
9
KBINH
10
LILED
11
RSMRST#
12
ACTLED
13
ROMKBCS#(1)
14
SPDLED
15
EXT_PRG(1)
16
I2CLK
17
VCC
18
VCC
19
OVCR#
20
GPCS#(1)
21
EXTSMI#
22
I2DAT
23
SMBCLK
24
SMBDATA
25
SIDE_CS3#
26
SMBALRT#
27
SIDE_CS1#
28
DASP_S(1)
29
SIDE_A2
30
PIDE_CS3#
31
SIDE_A0
32
PIDE_CS1#
33
GND
34
GND
35
PDIAG_S
36
PIDE_A2
37
SIDE_A1
38
PIDE_A0
39
SIDE_INTRQ
40
PIDE_A1
41
BATLOW#
42
GPE1#(2)
43
SIDE_ACK#
44
PIDE_INTRQ
45
SIORDY
46
PIDE_ACK#
47
SIDE_IOR#
48
PIORDY
49
VCC
50
VCC
Pin
Signal
Pin
Signal
51
SIDE_IOW#
52
PIDE_IOR#
53
SIDE_DRQ
54
PIDE_IOW#
55
SIDE_D15
56
PIDE_DRQ
57
SIDE_D0
58
PIDE_D15
59
SIDE_D14
60
PIDE_D0
61
SIDE_D1
62
PIDE_D14
63
SIDE_D13
64
PIDE_D1
65
GND
66
GND
67
SIDE_D2
68
PIDE_D13
69
SIDE_D12
70
PIDE_D2
71
SIDE_D3
72
PIDE_D12
73
SIDE_D11
74
PIDE_D3
75
SIDE_D4
76
PIDE_D11
77
SIDE_D10
78
PIDE_D4
79
SIDE_D5
80
PIDE_D10
81
VCC
82
VCC
83
SIDE_D9
84
PIDE_D5
85
SIDE_D6
86
PIDE_D9
87
SIDE_D8
88
PIDE_D6
89
GPE2#(3)
90
CBLID_P#
91
RXD-
92
PIDE_D8
93
RXD+
94
SIDE_D7
95
TXD-
96
PIDE_D7
97
TXD+
98
HDRST#
99
GND
100
GND
(1) These pins are not connected.
(2) GPE1# is for case open detection.
(3) GPE2# is for system wake-up.
