Page 8 cExpress-BT2
1. Introduction
The cExpress-BT2 is a COM Express® COM.0 R2.1 Type 2 module supporting the Intel® Atom™ E3800 processor and Intel® Celeron®
processor, memory controller, and graphics processor on a single-chip design. The cExpress-BT2 is specifically designed for customers who
need high-level processing and graphics performance with low power consumption in a long product life solution.
The cExpress-BT2 features the Intel® Atom™ E3800 processor and Intel® Celeron® processor supporting non-ECC type DDR3L dual-
channel memory at 1066/1333 MHz to provide excellent overall performance.
Integrated Intel® 7 th Generation HD Graphics includes features such as OpenGL 3.1, DirectX 11, OpenCL 1.1 support for H.264, MPEG2,
VC1, VP8 hardware decode. Graphics outputs include VGA and dual-channel 18/24-bit LVDS. The cExpress-BT2 is specifically designed for
customers with high-performance graphics processing requirements who want to outsource the custom core logic of their systems for
reduced development time.
The cExpress-BT2 has dual stacked SODIMM sockets for up to 8 GB non-ECC type DDR3L memory. In addition, an onboard eMCC
memory is supported (optional, 8GB/16GB/32GB).
The cExpress-BT2 features a single onboard Gigabit Ethernet port, USB 2.0 ports, PATA and SATA 3 Gb/s ports, and PCI 2.3. Support is
provided for SMBus and I
2 C. The module is equipped with SPI AMI EFI BIOS with CMOS backup, supporting embedded features such as
remote console, CMOS backup, hardware monitor, and watchdog timer.
