Page 40 cExpress-BT2
6.4. PCI Configuration Space Map
Bus Number Device Number Function Number Routing Description
00h 00h 00h N/A Soc Transaction Router
00h 02h 00h Internal Graphics & Display
00h 10h 00h Internal Storage Control Cluster(MMC Port)
00h 11h 00h Internal Storage Control Cluster(SDIO Port)
00h 12h 00h Internal Storage Control Cluster(SD Port)
00h 13h 00h Internal SATA
00h 14h 00h Internal xHCI USB
00h 18h 00h Internal Serial IO(SIO:DMA)
00h 18h 01h Internal Serial IO(SIO:I2C Port 1)
00h 18h 02h Internal Serial IO(SIO:I2C Port 2)
00h 1Ah 00h Internal Trusted Execution Engine
00h 1Bh 00h Internal HD Audio
00h 1Ch 00h Internal PCI Express Root port 1
00h 1Ch 01h Internal PCI Express Root port 2
00h 1Ch 02h Internal PCI Express Root port 3
00h 1Ch 03h Internal PCI Express Root port 4
00h 1Dh 00h Internal EHCI USB
00h 1Fh 00h N/A Platform Controller Unit(LPC)
00h 1Fh 03h Internal SMBus Controller
03h 00h 00h Internal Texas Instruments PCI-to-PCI Bridge
05h 00h 00h Internal Intel Corporation Ethernet Controller
