Page 8 Express-HL
2.4 Audio
¾ Integrated: Intel® HD Audio integrated in PCH QM87/QM86
¾ Audio Codec: Realtek ALC886 on Express-BASE6
2.5 LAN
¾ Integrated: LAN MAC integrated in PCH QM87/HM86
¾ Intel PHY: Intel® Ethernet Controller i217LM
¾ Interface: 10/100/1000 GbE connection
2.6 Multi I/O and Storage
¾ Integrated in Intel® QM87/HM86 Chipset
¾ USB ports: 4 ports USB 3.0 (USB0,1,2,3) and 4 ports USB 2.0 (USB4,5,6,7) – QM87
¾ 2 ports USB 3.0 (USB0, 1) and 6 ports USB 2.0 (USB3, 4, 5, 6, 7) – HM86
¾ SATA ports: 4 ports SATA 6Gb/s (SATA0, SATA1, SATA2, SATA3) – QM87
¾ 2 ports SATA 6Gb/s (SATA0, 1) and 2 ports SATA 3Gb/s (SATA2, 3) – HM86
¾ Serial: 2 UART ports COM1/2 with console redirection
¾ GPIO: 4 GPO and 4 GPI
2.7 TPM (Trusted Platform Module)
¾ Chipset: ATMEL AT97SC3204
¾ Type: TPM 1.2
2.8 SEMA Board Controller
¾ Type: ADLINK Smart Embedded Management Agent (SEMA)
¾ Supports:
• Voltage/Current monitoring
• Power sequence debug support
• AT/ATX mode control
• Logistics and Forensic information
• Flat Panel Control
• General Purpose I2C
• Failsafe BIOS (dual BIOS )
• Watchdog Timer and Fan Control
2.9 Debug
¾ 40-pin flat cable connector to be used with DB-40 debug module
• supports: BIOS POSTCODE LED, BMC access, SPI BIOS flashing, Power Testpoints, Debug LEDs
¾ 60-pin XDP header for ICE debug of CPU/Chipset
