4 Connector Pinouts on Module
This chapter describes connectors and pinouts, LEDs and switches that are used on the module but are not included in the PICMG standard
specification
¾
Connector and LED Locations
CD
AB
FAN
4-pin
FAN
40-pin
Debug connector
BIOS
Defaults
RESET
Button
XDP 60-pin to CPU
