Page 72 Express-HL
7.4 Boot
7.4.1 Boot Configuration
Feature Options Description
Boot Configuration Info only
Setup Prompt Timeout 1 Enable/Disable the onboard SATA controllers.
Bootup NumLock State On Select SATA controller mode.
Quiet Boot Disabled
Enabled
Enable/Disable the PATA port. In fact this enables or disables the
SATA channel on which the onboard SATA to PATA converter is
attached. When set to enabled the system boot will be delayed for
the time specified in PATA Port Detection Timeout if no PATA
device is connected.
Auto: Scan for PATA device and enable per default.
Fast Boot Disabled
Enabled Define the maximum time to wait for drive detection on PATA port.
Boot Option Priorities Info only
CSM16 Parameters Submenu
CSM16 Module Version Info only
GateA20 Active Upon Request
Always UPON REQUEST - GA20 can be disabled using BIOS services.
ALWAYS - do not allow disabling GA20; this option is useful when
any RT code is executed above 1MB.
Option ROM Messages Force BIOS
Keep Current Set display mode for Option ROM.
INT19 Trap Response Immediate
Postponed BIOS reaction on INT19 trapping by Option ROM: IMMEDIATE -
execute the trap right away; POSTPONED - execute the trap during
legacy boot.
CSM parameters Submenu
7.4.2 CSM parameters
Feature Options Description
Launch CSM Enabled
Disable This option controls if CSM will be launched.
Boot Option filter UEFI and Legacy
Legacy only
UEFI only This option controls what devices system can to boot.
Launch PXE OpROM policy Do not launch
Legacy only
UEFI only Controls the execution of UEFI and Legacy PXE OpROM.
Launch Storage OpROM policy Do not launch
UEFI only
Legacy only Controls the execution of UEFI and Legacy Storage OpROM.
Launch Video OpROM policy Do not launch
UEFI only
Legacy only Controls the execution of UEFI and Legacy Video OpROM.
Other PCI device ROM priority UEFI OpROM
Legacy OpROM For PCI devices other than Network, Mass storage or Video defines
which OpROM to launch.
