4.3 XDP Debug Header
The debug port is a connection into a target-system environment that provides access to JTAG, run control, system control, and observation
resources. The XDP target system connector is a Samtec™ 60-pin BSH-030-01 series connector.
Pin XDP Signal Target Signal I/O Device Pin XDP Signal Target Signal I/O Device
1 GND GND NA 2 GND GND NA
3 OBSFN_A0 PREQ# I/O processor 4 OBSFN_C0 CFG[17]2 I processor
5 OBSFN_A1 PRDY# I/O processor 6 OBSFN_C1 CFG[16]2 I processor
7 GND GND NA 8 GND GND NA
9 OBSDATA_A0 CFG[0]2 I/O processor 10 OBSDATA_C0 CFG[8]2 I/O processor
11 OBSDATA_A1 CFG[1]2 I/O processor 12 OBSDATA_C1 CFG[9]2 I/O processor
13 GND GND NA 14 GND GND NA
15 OBSDATA_A2 CFG[2]2 I/O processor 16 OBSDATA_C2 CFG[10]2 I/O processor
17 OBSDATA_A3 CFG[3]2 I/O processor 18 OBSDATA_C3 CFG[11]2 I/O processor
19 GND GND NA 20 GND GND NA
21 OBSFN_B0 BPM#[0]1 I/O processor 22 OBSFN_D0 CFG[19]2 I/O processor
23 OBSFN_B1 BPM#[1]1 I/O processor 24 OBSFN_D1 CFG[18]2 I/O processor
25 GND GND NA 26 GND GND NA
27 OBSDATA_B0 CFG[4]2 I/O processor 28 OBSDATA_D0 CFG[12]2 I processor
29 OBSDATA_B1 CFG[5]2 I/O processor 30 OBSDATA_D1 CFG[13]2 I processor
31 GND GND NA 32 GND GND NA
33 OBSDATA_B2 CFG[6]2 I/O processor 34 OBSDATA_D2 CFG[14]2 I/O processor
35 OBSDATA_B3 CFG[7]2 I/O processor 36 OBSDATA_D3 CFG[15]2 I/O processor
37 GND GND NA 38 GND GND NA
39 HOOK0 PWRGOOD I system 40 ITPCLK/HOOK4 Open NA
41 HOOK11 BP_PWRGD_RST# O system 42 ITPCLK#/HOOK5 Open NA
43 VCC_OBS_AB VCCIO_OUT I system 44 VCC_OBS_CD VCCIO_OUT I system
45 HOOK2 PWR_DEBUG O processor 46 HOOK6/RESET# PLTRSTIN# I system
47 HOOK3 PCH_SYS_PWROK O system 48 HOOK7/DBR# DBR# O system
49 GND GND NA 50 GND GND NA
51 SDA1 SDA I/O system 52 TDO TDO I processor
53 SCL1 SCL I/O system 54 TRSTn TRST# O processor
55 TCK1 Open NA 56 TDI TDI O processor
57 TCK0 TCK O processor 58 TMS TMS O processor
59 GND GND NA 60 GND G ND (or XDP_
PRESENT# if required) NA
Notes:
1. These signals are optional, can be left as OPEN/No-Connect if debug by Intel will not be needed.
2. These CFG signals can be left as Open/No Connect if not used as a strapping signal and top side probe will be used to debug
processor.
Refer to the "Shark Bay and Denlow Platforms Debug Port Design Guide (DPDG)", Document Number: 479493, Revision: 1.2
