Specifications 7
cPCI-3615
2 Specifications
2.1 cPCI-3615 Specifications
CompactPCI®
Standards • PICMG® 2.0 CompactPCI® Rev. 3.0
• PICMG® 2.1 Hot Swap Specification Rev.2.0
Mechanical • Standard 3U CompactPCI®
• Board size: 100mm x 160mm
• Single-slot (4HP, 20.32mm); Dual-slot (8HP, 40.64mm),
Triple-slot (12HP, 60.96mm) width
• CompactPCI® connectors with J1, J2
Processor • µFC-BGA Intel® Atom™ Processor N455
1.66 GHz, 512KB L2 cache, TDP 6.5W
• µFC-BGA dual-core Intel® Atom™ Processor D525
1.8 GHz, 1MB L2 cache, TDP 13W
• Passive heatsink
Chipset • Intel® ICH8M I/O Controller Hub (ICH)
Memory • Single channel unbuffered DDR3-800 SDRAM soldered
onboard
• Up to 2GB for N455 processor, 4GB for D525 processor
BIOS • AMIBIOS8® 16Mbit SPI flash memory
CompactPCI
Bus • PCI 32bit/ 33MHz; 3.3V, 5V universal V(I/O)
• Supports operation in system slot only
Gigabit
Ethernet • Two PCI-Express x1 Intel® 82574L GbE controllers
• Two egress 10/100/1000BASE-T ports, configurable to J2
(RTM) by software setting
Graphics • Integrated in Intel® Atom™ Processor
• DB-15 VGA port on front panel, switchable to J2 (RTM)
• Analog monitor support up to QXGA 2048x1536 @60Hz
32-bit
Serial Ports • Up to three 16C550 compatible RS-232/422/485/485+
serial ports from Super I/O IT8783
• One DB-9 port on front panel, two DB-9 ports on rear panel
Storage
Interface
1
• CompactFlash Type II socket onboard
• 2.5” SATA HDD connector onboard (8HP/12HP version only)
• Two 7-pin SATA signal connectors on RTM
PMC/XMC • One 32bit/66MHz PMC or PCI-Express x1 XMC site
(12HP version only)
Audio • Line-in and Line-out ports on front panel (8HP/12HP only)
• Realtek ALC262 High Definition Audio Codec
BIOS • AMIBIOS8® 16Mbit SPI flash memory
