38 ViewCreator Pro Utility
Table A-5: SDI (BNC) Available Formats
A.0.6 Color Format Menu
Sets the captured image to the selected color format.
Table A-6: Available Color Formats
A.0.7 Audio Format Menu
Sets the audio format, with available Sample Rates and Channels
variable according to the input selected.
Table A-7: Available Audio Formats
1080i 25 fps 1920 x 1080
1080i 29.97/30 fps 1920 x 1080
1080p 23.98/24 fps 1920 x 1080
1080p 25 fps 1920 x 1080
1080p 30 fps 1920 x 1080
1080p 50 fps 1920 x 1080
1080p 59.97/60 fps 1920 x 1080
YCbCr 4:2:2 8bit (YUY2)
YCbCr 4:4:4 8bit (YUV8)
RGB 4:4:4 8bit (RGB24)
YCbCr 4:2:2 10bit (YU10)
YCbCr 4:4:4 10bit (YUV10)
RGB 4:4:4 10bit (GBR30)
YCbCr 4:2:2 12bit (YU12)
YCbCr 4:4:4 12bit (YUV12)
RGB 4:4:4 12bit (RGB36)
Sampling Rate 48 kHz
Sample Bits
16 bit
20 bit
24 bit
Channels 2.0 (2)
Format Resolution
