Getting Started 25
PCIe-2602
2 Getting Started
2.1 Unpacking Checklist
Before unpacking, check the shipping carton for any damage. If
the shipping carton and/or contents are damaged, inform your
dealer immediately. Retain the shipping carton and packing
materials for inspection. Obtain authorization from your dealer
before returning any product to ADLINK. Ensure that the fol-
lowing items are included in the package.
X
PCIe-2602 unit
X
Quick Start Guidel
2.2 Installation
The following describes installation of the PCIe-2602 module on
the PCI express bus.
1. Remove the computer cover according to the computer
manual..
2. Remove the slot cover (if any).
3. Carefully position the PCIe-2602 in the selected PCI
express slot. If installing in a tower computer, align the
board with the board slots.
4. Press the board firmly but carefully into the connector.
5. Anchor the board with the screw.
6. Connect the SDI source and PCIe-2602 with the BNC
coaxial cable.
NOTE: NOTE:
OEM versions with non-standard configuration, functionality, or
packaging may vary according to individual requirements.
NOTE: NOTE:
A vacant PCI express slot is required for installation of the
PCIe-2602 module; if none is available, remove a PCI express
board and note the slot number.
