16 Introduction
Table 1-9: Card ID Switch Settings (S1)
Table 1-10: D I/O Switch Settings (S4)
Card ID Slider 1 Slider 2 Slider 3 Slider 4
15 on on on on
14 off on on on
13 on off on on
12 off off on on
11 on on off on
10 off on off on
9 on off off on
8 off off off on
7 on on on off
6 off on on off
5 on off on off
4 off off on off
3 on on off off
2 off on off off
1 on off off off
0 off off off off
DI Channel DI Status Slider Setting
DI0 Pulled high to +5V 1 On
DI0 Low 1 Off
DI1 Pulled high to +5V 2 On
DI1 Low 2 Off
DI2 Pulled high to +5V 3 On
DI2 Low 3 Off
DI3 Pulled high to +5V 4 On
DI3 Low 4 Off
