Introduction 5
PCIe-2602
Input High Threshold
for WAKE#, PERST# ,
SMCLK and SMDAT
+2.0V +3.45V
Input Low Threshold
for WAKE#, PERST#,
SMCLK and SMDAT
-0.3V +0.8V
Digital Input
Number of Channels
4 digital inputs
Input Resistance 1 KΩ
Input High Threshold 2V 12V
Test
condition:
Ta=25℃
Input Low Threshold 0V 0.8V
Input power
dissipation
0W 0.17W
Input signal
Frequency
1kHz
Test
condition:
Ta=25℃
Digital Output
Number of Channels
4 digital outputs
Output sink current 50mA
Test
condition:
Ta=25℃
Output Type Open collect/TTL
Power on status
Open
collect
mode
TTL mode
High Z
High
State(+5V)
Response Time 1kHz
Test
condition:
Ta=25℃
Parameter Min. Type Max. Comment
