ViewCreator Pro Utility 29
PCIe-2602
A.0.2 Tool Panel
Tool Button Function
ContinueGrab
.
Toggles continuous acquisition of images
SnapShot
.
Captures a single image
Hide/Show Image
.
Toggles display of the image
FitSize
.
Resizes the image to fit the display area
OriginalSize
.
Restores the image to original size
ZoomIn
.
Increases image closeup
ZoomOut
.
Decreases image closeup
FocusCross
.
Displays blue crosshairs at any selected point
on the image, the pixel values of which are
displayed on the Status Panel
Focus Value
.
(See FocusValue Operating Details)
Histogram
.
Opens a window showing the histogram of the
display region
Fourier
Transform
.
Opens a window showing the
Fourier-Transformed image
