DirectShow Programming Guide 69
PCIe-2602-FLR
Output format can be detected and reported to the application,
with supported formats as described, where -1 indicates a
non-supported format, or no embedded video payload identifi-
cation. The output format can be detected only if the input sen-
sor conforms to SMPTE 352M.
EXAMPLE
LONG Format;
DWORD dwReturn;
m_pKsPropertySet->Get( PROPSETID_AVS260X_CUSTOM,
CUSTOM_PROPERTY_GET_DETECTED_OUTPUT_FORMA
T,
NULL, 0,
&Format, sizeof(LONG), &dwReturn);
11.CUSTOM_PROPERTY_XET_DO
The property sets or retrieves of all DO status, with supported
values of each bit (bit 0 to bit 4):
0: low
1: high
Format Value
YCbCr 4:2:2 8 bit 0
YCbCr 4:4:4 8 bit 1
RGB 8bit 2
YCbCr 4:2:2 10 bit 3
YCbCr 4:4:4 10 bit 4
RGB 10 bit 5
YCbCr 4:2:2 12 bit 6
YCbCr 4:4:4 12 bit 7
RGB 12bit 8
