60 DirectShow Programming Guide
Compression (FOURCC code) is ‘YU10’ and GUID is
30315559-0000-0010-8000-00AA00389B71
MEDIASUBTYPE_YUV10 - 30bit YCbCr 4:4:4 – 10bit Y + 10bit Cb +
10bit Cr
Compression (FOURCC code) is ‘YUVA’ and GUID is
41565559-0000-0010-8000-00AA00389B71
MEDIASUBTYPE_BGR30 - 30bit RGB – 8bit R + 8bit G + 8bit B
Compression (FOURCC code) is ‘BGRA’ and GUID is
41524742-0000-0010-8000-00AA00389B71
MEDIASUBTYPE_YU12 - 24bit YCbCr 4:2:2 – 12bit Y + 12bit Cb/Cr
DWORD
Pixel Data [31:0]
[31:24] [23:16] [15:8] [7:0]
dw0 xxCr[9:4] Cr[3:0]Cb[9:6] Cb[5:0]Y[9:8] Y[7:0]
DWORD
Pixel Data [31:0]
[31:24] [23:16] [15:8] [7:0]
dw0 xxB[9:4] B[3:0]G[9:6] G[5:0]R[9:8] R[7:0]
DWORD
Pixel Data [31:0]
[31:24] [23:16] [15:8] [7:0]
dw0 Y1[7:0] Cb0[11:4] Cb0[3:0]Y0[11:8] Y0[7:0]
dw1 Cb2[3:0]Y2[11:8] Y2[7:0] Cr0[11:4] Cr0[3:0]Y1[11:8]
dw2 Cr2[11:4] Cr2[3:0]Y3[11:8] Y3[7:0] Cb2[11:4]
