Function Library 23
PCIe-2602-FLR
Return Value
No error occurs if return value ≥ 0; if a negative value,
please refer to Other Functions for return code error informa-
tion.
Get Video Capabilities
Acquires li1st of supported resolutions.
Syntax
C/C++
int Sdi_GetVideoCapabilities(UINT Number,
SDI_RESOLUTION_CAPABILITIES & Caps)
C#
int GetVideoCapabilities (uint Number, out
SDI_RESOLUTION_CAPABILITIES Caps)
VB.Net
GetVideoCapabilities (ByVal Number as UInte-
ger, ByRef Caps As
SDI_RESOLUTION_CAPABILITIES) As Integer
dw5 B5[11:4]
B5[3:0]
R4[11:8]
R4[7:0] G4[11:4]
dw6 B6[7:0] R5[11:4]
R5[3:0]
G5[11:8]
G5[7:0]
dw7
B7[3:0]
R6[11:8]
R6[7:0] G6[11:4]
G6[3:0]
B6[11:8]
dw8 R7[11:4]
R7[3:0]
G7[11:8]
G7[7:0] B7[11:4]
NOTE: NOTE:
Not all sensor formats support the output formats shown.
Please see the Specification section in the PCIe-2602 User’s
Manual.
DWORD
Pixel Data [31:0]
[31:24] [23:16] [15:8] [7:0]
