22 Function Library
7: 36bit YCbCr 4:4:4 – 12bit Y + 12bit Cb + 12bit Cr
8: 36bit RGB – 12bit R + 12bit G + 12bit B
DWORD
Pixel Data [31:0]
[31:24] [23:16] [15:8] [7:0]
dw0 Cr0[7:0] Cb0[11:4]
Cb0[3:0]
Y0[11:8]
Y0[7:0]
dw1
Cr1[3:0]
Cb1[11:8]
Cb1[7:0] Y1[11:4]
Y1[3:0]
Cr0[11:8]
dw2 Cb2[11:4]
Cb2[3:0]
Y2[11:8]
Y2[7:0] Cr1[11:4]
dw3 Cb3[7:0] Y3[11:4]
Y3[3:0]
Cr2[11:8]
Cr2[7:0]
dw4
Cb4[3:0]
Y4[11:8]
Y4[7:0] Cr3[11:4]
Cr3[3:0]
Cb3[11:8]
dw5 Y5[11:4]
Y5[3:0]
Cr4[11:8]
Cr4[7:0] Cb4[11:4]
dw6 Y6[7:0] Cr5[11:4]
Cr5[3:0]
Cb5[11:8]
Cb5[7:0]
dw7
Y7[3:0]
Cr6[11:8]
Cr6[7:0] Cb6[11:4]
Cb6[3:0]
Y6[11:8]
dw8 Cr7[11:4]
Cr7[3:0]
Cb7[11:8]
Cb7[7:0] Y7[11:4]
DWORD
Pixel Data [31:0]
[31:24] [23:16] [15:8] [7:0]
dw0 R0[7:0] G0[11:4]
G0[3:0]
B0[11:8]
B0[7:0]
dw1
R1[3:0]
G1[11:8]
G1[7:0] B1[11:4]
B1[3:0]
R0[11:8]
dw2 G2[11:4]
G2[3:0]
B2[11:8]
B2[7:0] R1[11:4]
dw3 G3[7:0] B3[11:4]
B3[3:0]
R2[11:8]
R2[7:0]
dw4
G4[3:0]
B4[11:8]
B4[7:0] R3[11:4]
R3[3:0]
G3[11:8]
