Specifications • 23
A.3 APS-940XA PSU Specifications
AC Input Characteristics
VOLTAGE: 90 ~ 240 VAC FULL RANGE.
FREQUENCY: 47 ~ 63 HZ.
INPUT CURRENT: 8.0 A (RMS) FOR 115VAC, 4.0 A (RMS) FOR
230VAC.
INRUSH CURRENT: 65A MAX. FOR 115 VAC, 125A MAX. FOR 230
VAC.
AC Input voltage is switching automatically according to AC input voltage.
The acceptable input voltage range is as following table.
Voltage Frequency Minimum Maximum Input Current
115 VAC 47 - 63Hz 90 VAC 130 VAC 8.0A (300W)
230 VAC 47 - 63Hz 180 VAC 260 VAC 4.0A (300W)
DC Output Characteristics
VDC Minimum Maximum
Ripple and
Noise Max Load
Regulation Line
Regulation
+5 V 3.0 A 35 A 50 mV
±5% ±1%
+12 V 2.0 A 30 A 120 mV +7%/-5%
±1%
-5 V 0 A 0.8 A 150 mV
±5% ±1%
-12 V 0 A 1.0 A 150 mV
±5% ±1%
+3.3 V 1.0 A 25 A 50 mV
±5% ±1%
+5Vsb 0.1 A 2 A 50 mV
±5% ±1%
REMARK: THE OUTPUT CURRENT OF 5V & 3.3V SHOULD NOT
EXCEED 45A.
SPECIFICATION:
Temperature range: Operating 0℃ --- 40℃.
Hold up time: 16 ms MINIMUM at full load & normal input voltage.
Dielectric Withstand: Input / Output 1500 VAC for 1 second.
Input to Frame Ground 1500 VAC for 1 second.
Efficiency: 68% Typical.
Power good signal: ON DELAY 100 ms to 500 ms, OFF DELAY 1 ms.
Over load protection: 130 +/- 20%.
Over voltage protection: +5V
Î 5.7V ~ 6.5V, 3.3V Î 3.9 ~ 4.3V, 12V Î
13.6 ~ 15V.
Short circuit protection: +5V, -5V, +12V, -12V, +3.3V.
