12 ● Backplane Overview
3.4 Peripheral Slots
There are 7 peripheral slots including the Star Trigger controller slot.
Figure 3.1 PXI Local Bus and Star Trigger Routing
3.5 Local Bus
The local bus of PXI backplane cBX-3008L is a daisy-chained bus that
connects each peripheral slot with its adjacent peripheral slots at the left
and right. Each local bus is 13 lines wide and can pass analog or digital
signals between modules, or provide a high-speed side-band
communication path that does not affect the PXI bandwidth.
In accordance with the PXI specification, the local bus connections
between all slots except slots 1 and 2.
PXI Trigger Bus Segment and PCI Bus Segment
PXI Star Triggers
Clock 10 MHz Buffer Circuitry
System
Contro
ller
1
Star
T
rigger
C
ontroll
er
2
Periph
era
l
slot
3
Periph
era
l
slot
4
Periph
era
l
slot
5
Periph
era
l
slot
6
Local
B
Local
B
Local
B
Local
B
Periph
era
l
slot
7
Periph
era
l
slot
8
Local
B
Local
B
