C/C++ Libraries
• 37
PCI_CH2_PB: CH2’s Port B
PCI_CH2_PC: CH2’s Port C
PCI_CH2_PCU: CH2’s Port C Upper Nibble
PCI_CH2_PCL: CH2’s Port C Low Nibble
PCI_CH3_PA: CH3’s Port A
PCI_CH3_PB: CH3’s Port B
PCI_CH3_PC: CH3’s Port C
PCI_CH3_PCU: CH3’s Port C Upper Nibble
PCI_CH3_PCL: CH3’s Port C Low Nibble
PCI_CH0_PAE: CH1’s Port A uses External Latch
PCI_CH0_PBE: CH1’s Port B uses External Latch
PCI_CH0_PCE: CH1’s Port C uses External Latch
PCI_CH1_PAE: CH2’s Port A uses External Latch
PCI_CH1_PBE: CH2’s Port B uses External Latch
PCI_CH1_PCE: CH2’s Port C uses External Latch
Note: 1.CH2 and CH3 are only available for PCI-7296.
2.Only CH0 is available for PCI-7224.
@ Return Code
ERR_NoError
