Steps:
1) Apply
thread
tape
to
the
thread
of
the
pendant
adapter
and
rotate
the
pendant
adapter
to
the
mount.
Secure
the
pendant
adapter
to
the
mount
with
a
set
screw
(supplied).
2) Loosen
the
lock
screws
of
the
adapter,
as
shown
below:
Figure
1-­‐4 Install
the
Pendant
Adapter
NOTE:
The
dimension
of
pendant
adapter
is
G1
1
2
.
3) Hook
the
back
box
of
the
speed
dome
to
the
mount
with
the
safety
rope.
Route
the
cables
through
the
mount.
4) Align
the
direction
label
of
pendant
adapter
with
the
label
of
the
back
box
to
install
the
speed
dome.
Rotate
the
back
box
counterclockwise
or
clockwise
tightly.
Secure
the
back
box
and
the
pendant
adapter
with
two
lock
screws.
NOTE:
Please
remove
the
protective
film
on
the
lower
dome
after
the
installation
is
finished.
①
②
①
②
Lock
Screw
Labels
Lock
Screw
Pendant
Adapter
Loosen
the
Lock
Screws
Safety
Rope
