Directed Electronics S660 - Manual (Page 36)

3 36 6
ttaabbllee ooff zzoonneess
When using the Diagnostic functions, use the Table of Zones to see which input has triggered the system. It is
also helpful in deciding which input to use when connecting optional sensors and switches.
N NO OTTEE: The Warn Away® response does not report on the LED.
lloonngg tteerrm m eevveenntt hhiissttoorryy
The system stores the last two full triggers in memory. These are not erasable. Each time the unit sees a full
trigger, the older of the two triggers in memory will be replaced by the new trigger. To access long term event
history:
1. With the ignition off, press and H HO OLLD D the Valet®/Program switch.
2. Turn on the ignition.
3. Release the Valet®/Program switch.
4. Press and release the Valet®/Program switch within 5 seconds. The LED will flash in groups
indicating the last two zones that triggered the unit for one minute or until the ignition
is turned off.
N NO OTTEE:: The Warn Away triggers are not stored to memory and will not be reported.
ZZO ON NEE N NO O.. TTR RIIG GG GEER R TTY YP PEE IIN NP PU UTT D DEESSCCR RIIP PTTIIO ON N
1 Multiplexed Input BLUE (H1/6)
2 Multiplexed Shock Sensor Input Mux BLUE wire.
3 Door Trigger GREEN (H1/5) and VIOLET (H1/7).
4 Multiplexed Shock Sensor Mux GREEN wire
5 Ignition Yellow ribbon harness wire
