sseeccoonnddaarryy hhaarrnneessss ((HH22)) wwiirree ccoonnnneeccttiioonn gguuiiddee
This wire sends a negative pulse every time the remote start is activated or the doors are unlocked. This can be
used to pulse the disarm wire of the vehicle's factory anti-theft device. Use a relay to send a (-) or (+) pulse to
the disarm wire as shown in the following diagrams.
R Reellaayy ffo orr N Neeg gaattiivvee ((--)) D Diissaarrm m W Wiirree R Reellaayy ffo orr P Po ossiittiivvee ((+ +)) D Diissaarrm m W Wiirree
This wire sends a negative pulse every time the remote start shuts down or the doors are locked. This can be
used to pulse the arm wire of the vehicle's factory anti-theft device. Use a relay to send a (-) or (+) pulse to the
arm wire.
This wire provides 200 mA programmable output. (See Feature Descriptions section of this guide.)
IIM MP PO OR RTTA AN NTT!! Never use this wire to drive anything but a relay or a low-current input! This tran-
sistorized output can only supply 200 mA, and connecting directly to a solenoid, motor, or other
high-current device will cause the module to fail.
This wire provides 200 mA programmable output. (See Feature Descriptions section of this guide.)
IIM MP PO OR RTTA AN NTT!! Never use this wire to drive anything but a relay or a low-current input! This tran-
sistorized output can only supply 200 mA, and connecting directly to a solenoid, motor, or other
high-current device will cause the module to fail.
H H2 2//4 4 V VIIO OLLEETT//B BLLA ACCK K cch haan nn neell 5 5 o ou uttp pu utt
H H2 2//3 3 G GR REEEEN N//W WH HIITTEE 2 20 00 0 m mA A ((--)) p prro og grraam mm maab bllee cch haan nn neell 4 4 o ou uttp pu utt
H H2 2//2 2 G GR RA AY Y//B BLLA ACCK K ffaacctto orryy aallaarrm m rreeaarrm m
H H2 2//1 1 LLIIG GH HTT G GR REEEEN N//B BLLA ACCK K ((--)) ffaacctto orryy d diissaarrm m o ou uttp pu utt
