White light illuminator
On bottom of KA-1MRD, move the LIGHT oontrol to right
AUTO position. When the ambient light beoomes dark,
the white light turns on automatioally. When oall button
on KA-DAR or MONITOR button on KA-1 MRD is
depressed, the illuminators projeot to the oaller up to
50om, 20" from the eamera. Baokground soene of
more than 50om, 20" will not be seen.
LIGHT control
Actual terminal locations
KA-1 MRD has oonneoting terminals on the
bank of the unit. Insert eaoh oonduotor into
the terminal until it looks firmly.
Ll L ISiSl blE I ai I a ^ 1 I 2 I 3| 4| 5
n n n n n n £ [
i) @ @ @ @ (g)
1 n n n n n
To door release
TolER-2 —
To MAW-B —
-TosubMK-1SD/B
Bottom view
KA-1 MRD
MOUNTING
KA-DAR
KA-DAR
1. Pull the tamperproof sorew oover out and
downward to expose sorew.
2. Loosen tamperproof sorew with the hexagonal
wrenoh (supplied).
3. Mount the bank frame to single-gang box.
4. Conneot the wires, and mount the KA-DAR to
baok frame, aligning on top.
5. Fasten the sorew and remount the sorew oover.
Open the screw cover
KA-DAR Screw cover Hexagonal wrench
Back frame Single-gang box
83.5mm
(3-5/16")
Screws supplied (2)
T amperproof
screw & cover
Surface wall mounting
Loosen
Screwdriver
KA-1 MRD
6
.
Remove the mounting braoket attaohed on baok
of KA-1 MRD.
Mount the braoket to single-gang box.
Conneot 2 wires non-polarized of KA-DAR on
the baok of KA-1 MRD (A1, A2).
Conneot two wires of power supply (-
1
-, -).
Aligning with the marks, insert the prongs of the
braoket in the holes of KA-1 MRD and pull
downward until it looks.
It is suggested that the KA-1 MRD is mounted in
suoh a manner that the upper part of the monitor
is at the height of approximately 160om, 5'3" from
the floor.
-
4
-
