ELECTRICAL INFORMATION
1 Electrical Requirements
It is your responsibility to have all electrical connections made by a properly licensed
and competent electrician to assure that the electrical installation is adequate and
conforms with local and state regulations or codes. In the absence of such codes, all
electrical connections, material and workmanship must conform to the applicable
requirements of the National Electric Code ANSI/NFPA No. 70 (Latest Edition).
IMPORTANT: Failure to comply with these codes or ordinances, and/or the requirement
stipulated in this manual can result in personal injury or component failure.
NOTE: Component failure due to improper installation voids the warranty.
It is recommended that a separate circuit serving each tumbler be provided. The dryer
must be connected with copper wire only. Do not use aluminum wire which could cause
a fire hazard.
NOTE: The use of aluminum wire voids the warranty.
2. Electrical Service
Electrical service recommended specs (per tumbler):
Voltage Phase
No. of Amp. Draw Per Wire
Wires
Tumbler Size
Breaker Size
Per Tumbler
115 1 8 #12 15 Amp.
IMPORTANT: The dryer must be connected to the electrical supply shown on the data
label located on the inside of the middle access (control) door.
WARNING: ANY DAMAGE DONE TO DRYER COMPONENTS DUE TO IMPROPER
VOLTAGE APPLICATION OR CONNECTIONS WILL AUTOMATICALLY VOID THE
WARRANTY.
3. Electrical Connections
A wiring diagram is included with each dryer showing the wiring connection sequence.
The electrical connections are made in a box located at the top of the dryer. The dryer
is shipped with three (3) connection leads (LI, L2/Neutral, and Ground) for each
tumbler.
Electrical Connection Leads
Black White Green
+
-
Positive Neutral Ground
(LI) (L2) (GND)
