Bolens 131-730A - Manual (Page 31)

131-050A
131-730A
PARTS LIST FOR TRANSAXLE MODEL 801-004
Ref.
No.
PART No. DESCRIPTION
Ref.
No.
PART No. DESCRIPTION
1
PE-770071 Case, Transaxle 36 PE-780108 Washer, Thrust
2
PE-778136 Gear, Spur (15 Teeth) 37 PE-780121 Bearing, Ball
2A PE-778145 Gear, Spur (12 Teeth) 38 PE-780113 Washer, Flat
3 PE-778126A Gear, Spur (20 Teeth) 39 PE-780119 Bearing, Ball
4 PE-778127A Gear, Spur (25 Teeth) 41 PE-788051 Ring, Square cut
5 PE-778129A Gear, Spur (30 Teeth) 42 PE-788057 Ring, Square cut 6
PE-778121A Gear, Spur (20 Teeth) 43 PE-780112 Bearing, Needle
7 PE-778123A Gear, Spur (25 Teeth) 44 PE-780114 Washer, Flat 8
PE-778124A Gear, Spur (30 Teeth) 46 PE-788056 Ring, Square cut
9 PE-778122A Gear, Spur (22 Teeth) 47 PE-772082 Cover, Transaxle
10
PE-778128A Gear, Spur (28 Teeth) 48 PE-784290 Rod & Ford Assy., Shift 11
PE-778146 Gear, Spur (37 Teeth) 49 PE-776140 Shaft, Input
12
PE-778137 Gear, Bevel (42 Teeth) 50 PE-776184 Shaft, Brake
13 PE-784266 Collar, Shift 51 PE-790007 Plate, Brake pad
14 PE-786083 Sprocket (18 Teeth) 52 PE-790006 Pad, Brake
15 PE-786082 Sprocket(9 Teeth) 53 PE-786026 Pin, Dowel
16 PE-776204 Shaft, Counter 54 PE-792075 Locknut, 5/16-24
17 PE-778113A Bevel Pinion, Input 55 PE-792076 Washer, Flat
18 PE-786074 Spacer 56 PE-790013 Lever, Brake
19 PE-778138 Pinion, Output 57 PE-792073 Screw, Hex Hd., Thread
20
PE-778139 Gear, Output forming, 1/4-20x 1-1/4
21
PE-790003 Disk, Brake 58 PE-790005 Holder, Brake pad
22
PE-792089A Key 59 PE-778053A Gear Assy., Differential (Incl.
24 PE-780001 Washer 2 of No. 60)
25 PE-788040 Ring, Retaining 60 PE-780064 Bushing
26 PE-780105 Bushing, Flanged 60A PE-780120 Bushing
27 PE-780118 Bushing, Flanged 61 PE-778067 Gear, Bevel
28 PE-786081 Chain, Roller (No. 41 chain. 62 PE-778068 Pinion, Bevel
22
links 63 PE-786034 Pin, Drive
29 PE-780072 Washer, Thrust 64 PE-780065 Washer, Thrust
30 PE-780122 Bearing, Needle 65 PE-788038 Ring, Retaining
31 PE-792077 Ball, Steel
66
PE-792040 Pin, Roll
32 PE-780109 Washer, Thrust 67 PE-780001 Washer, Thrust
33 PE-792078 Screw, Set, 3/8-16 x
68
PE-774436 Axle (15-1/4" long)
3/8 69 PE-774435 Axle (13-3/8" long)
34 PE-792079 Spring 70 PE-792035 Ring, Retaining
35 PE-792073 Screw, Hex. Hd., thread 71 PE-792074 Plug, Hex Hd., 9/16-18
forming, 1/4-20 x 1-1/4 thread
NOTE: This unit is not under warranty by
the mower manufacturer. All Part Orders
and Service must be handled through the
local Authorized Tecumseh Service Dealer.
Find It Fast
In The
Yellow Pages
PEERLESS MODEL 801-004
This unit is under warranty by Tecumseh
Products Company. Parts and Service are
available theough all Tecumseh, Lauson
Power Products Service Dealers. Check the
"Yellow PagesI' of your telephone directory
under "Engines - Gasoline".
31
