131-050A
131-730A
PARTS LIST FOR DRIVE SYSTEM MODEL 131-050A and 131-730A
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1
756-0341
8" “V”-Pulley (Transaxle)
32
14073
Hand Brake Lever Ass’y.
2
736-0921
L-Wash. V
2
" I.D.*
33
720-0189
Grip—Flat Bar 1V4" Wide
3
712-0922
Hex Nut 1/2-20 Thd.*
34
748-0278
Spacer
4
14066
Transaxle Brace
35
738-0129
Shoulder Bolt .496" Dia. x
5
737-0322
Belt Guard
2.00" Lg. (3/8-16)
6
754-0248
“V”-Belt 1/2"
X
89" Lg.
36
732-0384
Extension Spring .620"
(Kevlar)
C.D.
X
6.12" Lg.
7
756-0116
“V”-Belt Idler Pulley .38"
37
13887
Deck Control Brkt.
I.D.
X
3-1/16" O.D.
38
747-0307
Deck Control Rod
8
738-0155
Shoulder Bolt .435" DIa. x
39
710-0442
Hex Bolt 5/16-18
X
1.50"
.160 (5/16-18)
Lg.*
9
756-0342
Two Step Engine Pulley
40
13833
Parking Brake Cam Mtg.
3.10" & 5.56" Dia.
Brkt.
10
712-0798
Hex Nut 3/8-16 Thd.*
41
712-0267
Hex Nut 5/16-18 Thd.*
11
736-0169
L-Wash. 3/8" I.D.*
42
736-0119
L-Wash. 5/16" I.D.*
12
756-0225
Flat Idler Pulley 2.75" O.D.
43
710-0459
Hex Bolt 3/8-24 x 1.50" Lg.
13
736-0105
Belleville Wash. .400" I.D.
(Grade 5)
X
.88" O.D.
X
.063
44
731-0483
Convoluted Conduit .50" I.D.
14
14076
Idler Bracket Ass’y-
X
4.0" Lg.
15
756-0293
4" “V”-ldler Pulley
45
732-0308
Ext. Spring .50" C.D. x 6.37"
16
710-0342
Hex Bolt 3/8-16
X
1.25" Lg.*
Lg.
17
714-0104
Hairpin Cotter 5/16" Dia.
46
710-0726
Hex Wash. Hd. AB Tap Scr.
' 18
735-0196
Foot Pad
5/16-24
X
.75" Lg.
19
736-0169
L-Wash. 3/8" I.D.*
47
—
Transaxle (See Breakdown
20
712-0798
Hex Nut 3/8-16 Thd.*
on Page
21
714-0145
Hairpin Cotter 3/8" Dia.
48
710-0378
Hex Bolt 5/16-18
X
2.50"
22
747-0318
Brake Clutch Rod (4.60" Lg.)
Lg.*
23
13859
Clutch Rod Bearing Brkt.
49
710-0726
Hex Wash. Hd. AB Tap Scr.
24
714-0474
Cotter Pin 1/8" Dia. x 1.00"
5/16-24
X
.75" Lg.
Lg.*
50
732-0433
Extension Spring .50"
25
14040
Clutch Brake Pedal Ass’y.
O.D.
X
2.75" Lg.
26
747-0319
Brake Cam Rod (13.60" Lg.)
51
714-0129
Hi-Pro Key 3/32"
X
27
732-0381
Extension Spring .59" O.D. x
5/8" Dia.
.93" Lg.
52
717-0234
Special Wash. 1.00"
28
712-0267
Hex Nut 5/16-18 Thd.*
O.D. (Hdn.)
29
736-0119
L-Wash. 5/16" I.D.*
53
14193
Transaxle Belt Keeper Ass’y.
30
13832
Parking Brake Cam
54
14067
Transaxle Support Bracket
31
736-0101
FI-Wash. .406" I.D. x 1.00"
55
736-0119
L-Wash. 5/16" I.D.*
O.D.
X
.030 Thk.
56
712-0267
Hex Nut 5/16-18 Thd.*
25
