DETAILED COOLING CAPACITIES*
Air 85 95 105 115
E Capacity Total Capacity Total Capacity Total • Capacity Total
CFM W MBtuht System MBtuht System MBtuht System MBtuht System
B Total Senst KW* ** Total Sensi KW** Total Sensi KW** Total Sensi KW**
544B042 Outdoor Section With 517E/GN048 Indoor Section
72 47.1 23.4 4.60 44.5 22.4 4.92 42.0 21.5 5.24 39.2 20.5 5.54
1400 67 42.8 29.9 4.46 40.4 28.9 4.76 38.0 27.9 5.06 35.5 26.9 5.34
62 38.9 36.0 4.33 36.8 34.9 4.62 34.6 33.7 4.90 32.5 32.3 5.17
57 37.8 37.8 4.29 36.1 36.1 4.59 34.3 34.3 4.88 32.4 32.4 5.17
72 47.8 24.3 4.71 45.0 23.3 5.03 42.4 22.4 5.36 39.4 21.3 5.66
1575 67 43.5 31.5 4.58 41.0 30.5 4.88 38.4 29.5 5.18 35.7 28.4 5.46
62 39.7 38.1 4.45 37.5 36.8 4.74 35.4 35.3 5.03 33.4 33.4 5.32
57 39.1 39.1 4.43 37.2 37.2 4.73 35.3 35.3 5.03 33.4 33.4 5.32
72 48.3 25.1 4.82 45.4 24.1 5.14 42.7 23.2 5.46 39.7 22.2 5.77
1750 67 43.9 33.0 4.68 41.3 32.0 4.99 38.7 30.9 5.28 36.1 29.9 5.57
62 40.5 39.9 4.57 38.3 38.3 4.87 36.3 36.3 5.17 34.2 34.2 5.46
57 40.2 40.2 4.56 38.3 38.3 4.86 36.3 36.3 5.17 34.2 34.2 5.47
CONDENSER ENTERING AIR TEMPERATURES °F
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Capacity Power
Indoor
Section Size
Cooling
Capacity Power
506B
508A
042 0.98 0.96 519C 042
1.00
0.98
048 0.99 0.97 060 1.04 0.99
049 1.00 0.97 519C &
520B042 042 0.98 0.99
048
1.01
0.96 060 1.02
1.02
510B
517E/G
048
1.01
0.98 519D/509A 042 0.99 0.95
060 1.04 0.99 042X 0.99 0.95
042 0.99 1.00 042C 0.99 0.97
043 1.00 0.97 043 1.02 0.97
048
1.00
1.00 043X
1.02
0.97
049
1.01
0.98 048X
1.02
0.97
060
1.01
1.04 519D 048
1.02
0.97
062
1.01
1.03 048C
1.02
0.97
049 1.04 0.97
544B048 Outdoor Section With 517E/GN060 Indoor Section
1600
72
67
62
57 51.6
47.2
43.2
42.6 26.2
34.0
41.2
42.6 5.27
5.12
4.97
4.95 48.8
44.4
40.9
40.5
25.2
32.9
40.0
40.5
5.64
5.45
5.30
5.28
45.8
41.5
38.5
38.3
24.1
31.8
38.4
38.3
5.98
5.78
5.61
5.61 42.7
38.7
36.2
36.2 23.1
30.6
36.2
36.2 6.32
6.09
5.93
5.93
72 52.3 27.3 5.41 49.2 26.2 5.77 46.1 25.2 6.12 42.9 24.1 6.46
1800 67 47.8 36.0 5.25 45.0 34.9 5.59 42.1 33.7 5.92 39.1 32.5 6.23
62 44.1 43.5 5.12 41.9 41.8 5.45 39.6 39.6 5.79 37.2 37.2 6.11
57 43.9 43.9 5.11 41.7 41.7 5.45 39.4 39.4 5.78 37.3 37.3 6.12
72 52.8 28.4 5.54 49.5 27.2 5.89 46.3 26.2 6.24 43.0 25.1 6.59
2000 67 48.2 37.8 5.37 45.3 36.6 5.71 42.3 35.4 6.04 39.3 34.2 ■6.36
62 45.0 45.0 5.26 42.7 42.7 5.61 40.3 40.3 5.95 38.1 38.1 6.28
57 45.0 45.0 5.26 42.7 42.7 5.61 40.3 40.3 5.95 37.9 37.9 6.28
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Capacity Power
Indoor
Section Size
Cooling
Capacity Power
506B 048 0.96 0.96 519C 048 0.94 0.95
049 0.97 0.95 060 0.99 0.97
060 0.97 0.96 519C&
520B048 048 0.94 0.97
061 0.98 0.97 060 0.99 0.99
508A
510B
517E/G
048 0.98 0.94 519D/509A 048X 0.99 0.96
048 0.98 0.97 057C 1.02 0.95
060 1.02 0.98 060 1.02 0.97
048 0.96 0.98 061 1.07 0.96
049 0.99 0.96 519D 048 0.99 0.96
060 1.00 1.00 048C 0.99 0.95
062
1.01
1.00 049 1.02 0.95
063 1.02
1.01
*Detailed cooling capacities are based on indoor and outdoor unit at the same elevation and connected by 25 feet of tubing. If other than 25
feet of tubing is used and/or indoor unit is located above outdoor unit, a slight variation in capacity may occur.
fTotal and sensible capacities are net capacities. Blower motor heat has been subtracted.
^Sensible capacities shown are based on 80°F entering air at the indoor coil. For sensible capacities at other than 80°F, deduct 835 Btuh per
1000 Cfm of indoor coil air for each degree below 80°F, or add 835 Btuh per 1000 Cfm of indoor coil air per degree above 80°F.
**Unit KW is total of indoor and outdoor unit KW’s.
