SYSTEM
CONFIGURATION
System configuration and the eqxiipment list are as
shown below.
Desk Top
Battery Charger
List of Equipment
AC Adaptor
No.
Name of the Equipment
Handheld Portable Telephone
(D
Battery Pack
(D
Desk Top Battery Charger (DTC-500)
AC Adaptor (CNR-500)
BATTERY INSTALLATION
AND RECHARGING
The Portable Telephone contains a Detachable Bat
tery Pack (BTR-500). Fully charged Battery Pack
offers approximately 65 minutes Talk Time or 12
hours standby.
It is recommended to carry one fully charged spare
Battery Pack for longer operation.
(Additional Battery Packs may be purchased at your
Cellular Telephone Dealer.)
To Attach Battery Pack
(1) Position Battery Pack to the unit using the
indents on the Battery Pack as guides to the
lower end of the unit as shown by arrow ©.
(2) Press and slide the Battery Pack as shown by
arrow ® to lock the Battery Pack to the unit.
Indicators
To Detach Battery Pack
(1) Press the Release Buttons on both sides of the
Battery Pack as indicated by arrow ® while
sliding it down approximately 1/4" as shown by
arrow ®.
(2) Then lift up to remove the Battery Pack from the
unit.
