ni; 1"'

— MODEL

42D

SCHEMATIC

IGNITION SWITCH

POSITION CIRCUIT

“MAKE”

OFF

G + M + L

NONE

RUN/LIGHT

B + L

A +Y

RUN

B + L

NONE

START

B + L + S

NONE

YOUR TRACTOR

EQUIPPED W

ith

A SPECIAL

alternaior

y s t e m

THE LIGHTS ABE fJOT
CONNECTED TC-’ THE
BATTERY. BUT HAVE THEIR
OWN ELECTRICAI SOURCE.
BECAUSE OF THIS, THF

BRIGHTNESS OF THE [ Y W T S
WILL CHANGE WITH L NG!t ‘L
SPEED. AT IDLE THL I .CHTS

WILL DIM. ASTHE Er'(',ir:F |P
SPEEDED UP, THE LiGrITt
WILL BECOME THEIR BRIGHTEST.

NON^REMOVABLE

CONNECTIONS

REMOVABLE

CONNECTIONS

WIRING INSULATED CLIPS

NOTE: !F WIRING INSULATED CUPS WERE REMOVED FOR
SERVICING OF UNIT, THEY SHOULD BE REPLACED TO
PROPERLY SECURE YOUR WIRING.
