IVIUU Cl OOU PARTS LIST FOR MODEL 386 1riLLER
1EF. PART COLOR NEW REF. PART COLOR NEW
NO. NO. CODE DESCRIPTION PART NO. NO. CODE
DESCRIPTION
PART
1 —
Engine 27 717-0471 Sheave Half N
2 710-0599 Thread Rolling Scr. V4-20 x 28 741-0139 Ball Bearing
.50" Lg. 29 750-0146 Spacer
3 04899 —463 Belt Cover 30 04894 Idler Arm
4 15227 —463 Front Belt Guard Support 31 747-0387 Control Rod 3/8" Rod
Ass’y- 32 738-0140 ShId. Bolt .437 Dia. x .180
5 736-0114 Internal L-Wash V
2
" Dia. 34 714-0115 Cotter Pin 1/8 Dia.
6 710-0121 Hex Scr. 1 / 2-20 x .75 Spec. 35 714-0145 Inter. Cotter Pin V 2 " Dia.
7 717-0475 Variable Speed Pulley 36 14751 Pivot Arm Ass’y.
Ass’y- N 37 1545-029 Clevis Pin
8 756-0319 Idler Pulley 38
—
Tine Ass’y. (See Chart)
9 712-0262 Hex L-Nut 3/8-24 Thd. 39
—
Tine Ass’y. (See Chart)
10 756-0369 Pulley 4.75" Dia. 45 714-0149 Inter. Cotter Pin V 2 Dia.
11 736-0231 FI-Wash. 5/16 I.D. x 1.120" 48 710-0442 Hex Bolt 5/16-18 X 1.50"
O.D. Lg.
12 736-0119 L-Wash. 5/16" I.D.* 49 736-0170 Shake-Proof Washer
13 710-0371 Hex Scr. 5/16-18 x .88" Lg. 54 04883 —463 Tine Shield
14 710-0230 Hex Bolt 1/4-28 X .50 Lg. 55 750-0229 Spacer .635 I.D. x .88 O.D.
15 754-0265 V-Belt 1 / 2 " X 29" Lg. X 1.035 Lg.
16 754-0254 V-Belt 1 / 2 " X 19" Lg. 57 712-0267 Hex Nut 5/16-18 Thd.*
17 712-0204 L-Nut 1/2-13 Thd. 58 712-0158 Hex Cent. L-Nut 5/16-18
18 710-0158 Hex Scr. 5/16-24 x 1.25" Thd.
Lg- 59 09164 Reinforcement Plate
19 736-0119 L-Wash. 5/16" I.D.* 60 04900 Friction Wheel Ass’y.
20 736-0231 FI-Wash. 5/16" I.D. x 1.25" 61 736-0185 FI-Wash. 3/8" I.D. x .750"
O.D. O.D.
756-0349 Engine Pulley 62 710-0459 Hex Bolt 3/8-24 x 1 1 / 2 "
'22 714-0133 Sq. Key 3/16 x 1.50" Lg. Lg.
23 732-0376 Extension Spring 64 736-0162 FL-Wash.
24 710-0599 Hex Tapp. Scr. V4-20 x .50" 67 736-0156 FI-Wash.
Lg. 68 748-0198 Spacer
25 04898 —463 Belt Guard Support—Rear 69 712-0287 Hex Nut V 4 - 2 O Thd.
26 715-0124 Spring Pin Spiral 5/32 Dia. 70 736-0329 L-Wash. 1 / 4 " I.D.*
X .62" Lg. 71 736-0231 FI-Wash.
TINE CHART
Part No. Description
784-0091
784-0092
784-0093
784-0094
Inner Tine Ass’y. Comp.—L.H.
Inner Tine Ass’y. Comp.—R.H.
Outer Tine Ass’y. Comp. —L.H.
Outer Tine Ass’y. Comp.—R.H.
Heavy Duty Garden Tiller Attachments Available for All-Season Use
31-0106 Depth Gauge Wheels (Pair) 31-0123
31-0107 6-Tine Cultivator (Must be used \«ith
31-0106 Depth Gauge Wheels) 31-0144
31-0110 8" Furrower Opener
31-0111 15" Sweep Cultivator
31-0113 Pneumatic Tires, 13 x 5.00-6 (Pair)
31-0114 Wheel Weights (Pair) 31-0145
31-0115 Tire Chains, 13 x 5.00 (2 Link) (Pair)
31-0119
Tine Cultivating Shields w/Adapters
(Pair)
Lawn Aerator (Use with 31-0114 Wheel
Weights for added penetration)
“V”-Bar Cultivating Kit
Kit Includes; “V”-Bar Frame, 4-Point
Cultivating Tines, Hiller/Furrower,
Depth Gauge Wheels (Pair).
Depth Stake Cultivating Kit
Kit Includes: 8" Furrower Opener, 15"
Sweep Cultivator, 32" Leveling Rake,
Extra Depth Stake.
Note: Attachments are available through your local dealer or from the factory:
Agri-Fab Inc., 303 W. Raymond Street, Sullivan, Illinois 61951 (217) 728-4334
