PARTS LIST FOR M ODELS 675, 685, 24677 and 24687
Ref.
No.
PART
No.
COLOR
CODE
DESCRIPTION
New
Part
1
14532 - 488
Air Duct Assembly
N
2
736-0242
Belleville Wash. .34" I.D. x
.87" O.D.
3
720-0170
3-Arm Thumb Scr. 5/16-18 x
.75" Lg.
4
731-0516
Trim Strip 36.5" Lg.
N
5
14560
Impeller Guard ■
N
6
14549
Door Assembly
N
7
732-0335
Compression Spring
8
14546
Directional Discharge Ass'y.
(Includes Ref. No. 6 & 7)
N
9
T4562
Nozzle Ass'y.
N
10
14563
Nozzle Plate Ass'y.
N
11
712-0267
Hex Nut 5/16-18 Thd.*
12
736-0119
L-Wash. 5/16" I.D.
13
710-0191
Hex Blot 3/8-24
X
1.25" Lg.*
14
736-0217
L.-Wash. 3/8" IID. H.D.
15
14536 - 488
Air Vane Plate Ass'y. (675
and 24677)
N
14557 - 488
Air Vane Plate Ass'y. w/pulley
(685 and 24687)
N
16
14542 - 488
Blower Housing Complete
N
17
14541
Right Angle Bracket
N
18
710-0600
Hex Wash. Hd. Self Tap Scr.
5/16-18
X
.50" Lg.
19
712-0158
Hex Cent. L.-Nut 5/16-18 Thd.
20
736-0289
Shoulder Spacer .50" I.D. x
.135
21
710-0260
Carriage Bolt 5/16-18 x .62"
Lg.*
22
710-0170
Hex Locking Bolt 5/16-24 x
.62" Lg.
23
14539
Housing - Engine Brace Ass'y.
24
728-0143
Pop Rivet (5-Required)
25
14569
Wiper Retaining Strip
N
26
735-0214
Nozzle Wiper
N
*For faster service obtain standard nuts, boits and washers
locally. If these items cannot be obtained localiy, order by
part number and size as shown on parts list.
(488 - Mack Truck Yellow)
(497 - Yard-Man Red)
When ordering parts, if color or finish is important use the
appropriate coior code shown above, (e.g. Mack Truck Yellow
Finish —14542 (488).)
NOTE: The engine is not under warranty by
the vacuum manufacturer... If repairs or
service is needed on the engine, please
contact your nearest author
ized engine service outlet.
Check the “Yellow Pages" of
your telephone book under
“Engines—Gasoline.”
