Section 10 — Exploded Views and Parts Lists
^PARTS
LISTS
PRIMEPACT 66C and 66LP Recreational Vehicle Generators
Alternator and Control Panel - Drawing No.
0D3149-A
TEM
PART NO.
QTY.
DESCRIPTION
ITEM
PART NO.
QTY.
DESCRIPTION
1
0C9675
1
LOWER BEARING CARRIER
34
086317A
1
PANEL SUPPORT BRACKET
2
077005H
1
ROTOR ASSEM. PP55
35
075235
2
M5-0.8 x 30 LG. CAPSCREW
077004H
1
ROTOR ASSEM, PP66
36
082737
4
VIBRATION MOUNT
3
087844H
1
STATOR ASSEM, 55
37
049813
4
M6-1.0HEX NUT
087845H
1
STATOR ASSEM, 66
38
049815
1
M5-08
X
16 LG, HEX HD. CAPSCR.
4
073159
1
BALL BEARING
39
043182
2
M3-LOCK WASHER
5
031971
1
BALL BEARING
40
0A8475
3
#10-SPEC1AL LOCKWASHER
6
0C9674
1
UPPER BEARING CARRIER
41
053623
1
C/BREAKER 2,5A PP55
7
077006
4
STUD-STATOR
054502
1
C/BREAKER 3.0A PP66
8
052858
4
M8-T25 FLANGE LOCK NUT
42
0D2724
2
BOOT, ROCKER SWITCH
9
066386
1
BRUSH HOLDER
43
083049
1
REGULATOR VOLTAGE
10
066849
2
M5-0.8x16LG,TAPTITE
44
022152
6
M5-LOCK WASHER
11
027756
4
NYLON WASHER
45
051716
4
M5-0.8 HEX NUT
12
086314
1
GENERATOR TOP HOUSING
46
090144
1
C/BREAKER 20A. PP55
13
075234
1
RESISTOR
090145
1
C/BREAKER 30A, PP66
14
022473
2
%“l M6-FLAT WASHER
47
090145
1
C/BREAKER 30A. (ALL UNITS)
15
022097
5
V r/ M6-LOCK WASHER
48
025105
4
#6-32
X
y/' SCREW W/LOCK WASHER
16
074095
1
M6-1.0X60 LG, CAPSCREW
49
086315
1
PANEL COVER
17
090141
2
GROUND CABLE
50
090734
4
M4-0.7
X
12LG,CAPSCR.W/LOCK-
18
0A1658
2
SPECIAL LOCK WASHER,
WASHER & FLAT WASHER
19
074906
4
M6-1,0x20 LG, TAPTITE
51
022985
1
#6-FLAT WASHER
20
092234
1
CONTROLLER P,C,B,
52
032300
1
FUSE HOLDER
21
055440
2
M5-0.8
X
25mm CAPSCREW
53
022676
1
FUSEAGC-15A,
22
022129
4
5/16"/ M8 LOCKWASHER
54
087798
1
SWITCH S.RD.T, 6A,-(START-STOP)
23
045771
4
M8-T25 HEX NUT
55
092113
1
SWITCH S.P,D.T.-(FUEL PUMP)
24
086316
1
PANEL SHEET METAL
56
075210-A
1
TERMINAL BLOCK
25
053650
1
4-PIN CONNECTOR
57
0A8475-A
1
#8 SPECIAL LOCK WASHER
26
0C4258
1
CONDUIT ASSEMBLY
58
051715
1
M4-0.7 HEX NUT
27
075244
1
ASSEMBLY, REMOTE CABLE
59
090157
1
DECAL, CB RATING 30A.
28
023484-S
1
BUSHING
60
084867
4“
U- CHANNEL, RUBBER
29
074908
1
M5-0,8x 10 LONG TAPTITE
61
089438A
1
DECAL, CUSTOMER CON, PP55
30
075476
3
M4-0,7x 16 LG, CAPSCREW
089438B
1
DECAL, CUSTOMER CON. PP66
31
022264
4
#8/ M4-LOCK WASHER
62
031791
1
CLAMP, HOSE
32
065795
1
BAHERY CHARGER RECTIFIER
63
023897
3
#10/ M5-FLAT WASHER
33
090987
2
M3-0,5x12LG, PPHMS
Generac* Power Systems, Inc. 45
