fO ADJUST STEERING WHEEL ALIGNMENT
If steering wheel crossbars are not horizontal (left to right)
when
wheels
are positioned straight
forward,
remove steer
ing wheel and reassemble per instructions
in
the Assembly
section of this manual.
FRONl WHEfcl ryE4N/CAMBER
Thp front wheel toe-ir« and camber are not ddjustable on
your irdclor If damage has otcuned to affect ilie lioni
wheel toe-in or camber, contact your nearest authonzed
serves center/departmerii,
TO REMO¥E WHEEL FOR REPAIRS
(See Fig. 24)
Block up axle securely.
Remove axle cover, retaining hog .a-id washers to alow
wheel removal hear wheel contains a square key - Do not
lose,!.
Repair tire and reassemble.
On rear wheels only: align grooves in rear wheel hub and
axle, insert square key.
Replace washers and snap retaining ring securely in axle
groove.
Replace axle cover.
NOTE: To seal tire punctures and prevent flat tires due to
slow leaks, tire sealant may be purchased from your local
parts dealer. Tire sealant also prevents tire diy rot and
corrosion.
AXLE COVER
SQUARE KEY (REAR
WHEEL ONLY)
FIG. 24
FMGINEWITHAWEAr I
g. 25)
A
CAUTiOH » foil s,.Jd batw 'c- qfe-ier-
ateexplosivegases.
Keep
sparks,lame
and smoking materials away from bat
teries. Always wear eye protection
when around batteries.
If your battery is too weak to start the engine, it should be
recharged
(See BATTERY"
in the
CUSTOMER RE
SPONSIBILITIES
section of this manual).
If “jumper cables” are used for emergency starting, follow
this procedure:
IMPORTANT YOUR
tractor
IS EQUIPPED WITH A
VOLT NEGATIVE GROUNDED SYSTEM. THE OTHER
VEHICLE MUST ALSO BE A i2
VOLT
MEGA'IVE
GROUNDED SYSTEM. DO NOT USE YOUR TRACTOR
BATTERY TO START OTHER VEHICLES.
TO ATTACH JUMPER CABLES -
•
Connect
each end
of
the RED
cable
to the POSITIVE (+)
terminal of each battery, taking care not to short against
chassis.
•
Connect one end of the BLACK cable to the NEGATIVE (-
) terminal of fully charged battery.
•
Connect the other end of the BLACK cable to good CHAS
SIS GROUND, away from fuel tank and battery.
TO REMOVE CABLES, REVERSE ORDER -
•
BLACK cable first from chassis and then
from
the fully
charged battery.
•
RED cable last from both batteries.
POSmVE TERMINAL
NEGATIVE TERMINAL
CHASSIS-
POSITIVE
TERMINAL
CABLES
CHARGED
BATTERY
NEGATIVE
TERMINAL
FIG. 25
